SteamTurbine
High Integration
Single Arrangement
Skid Mounted without Opening
Efficiency Comparison Before & After Improvement
| Backpressure Steam Turbine | |
| Inlet pressure/Mpa.a | 8.83 |
| Inlet temperature/℃ | 530 |
| Exhaust pressure/Mpa.a | 1.8 |
| Rated output power/kW | 9000 |
| Stages before improving：2+4 | Improved stages：1+18 |
| Efficiency before improving：70-75% | Improved efficiency：79-86% |
| Condensing (Extraction) Steam Turbine | |
| Inlet pressure/Mpa.a | 8.83 |
| Inlet temperaure/℃ | 530 |
| Exhaust pressure/Mpa.a | 0.02（air cooled） |
| Rated output power/kW | 18000 |
| Staged before improving：2+8 | Improved stages：1+21 |
| Efficiency before improving：73-78% | Improved efficiency：80-87% |
